78 C-Series Display Reference Manual
Changing the radar range from the chart window
When the radar overlay is set to ON, the radar range is indicated in the top left-hand
corner of the chart window in the same color as the overlay. You can now change the
radar range:
Note:
If RDR RNG SYNC is set to ON (see page 76), the chart scale also changes
4.15 Recording where you have been
What is a track?
A track is an on-screen trail that represents the course you have taken. This trail is
made up of a series of track points which are created automatically. You can save the
track to create a permanent record of where you have been.
.
D7217-3
RADAR
OPTIONS...
D6585-1
RANGE
IN
OUT
D6607_2
FIND SHIP GOTO… ROUTES… TRACKS… PRESENTATION…
4nm North-Up (Relative Motion) Local
81221_4.book Page 78 Tuesday, February 28, 2006 5:24 PM
