3.13Toolsrequiredforinstallation

D12171-2

876

1.Powerdrill.

2.Jigsaw.

3.Pozidrivescrewdriver.

4.Adhesivetape.

5.Spannerforsurfacemountingorbracketmountingxings.

6.File.

7.Holesawforushmounting(Forholesawsizerefertoyour

product’smountingtemplate).

8.Drillbitforsurfacemountingorbracketmounting.
