6.7Homescreenoverview—Newa
Series
Thehomescreenprovidesacentralpointofaccesstoyour
display'srangeofapplications.
•Thehomescreenalsoprovidesquickaccesstoyourdata
(waypoints,routes,andtracks).
•Thehomescreenconsistsofanumberofapplication"pages",
eachrepresentedbyanicon.Applicationscanbestartedby
selectingtherelevantpageicon.
•Swipethescreenwithyourngertoscrollthehomescreen
andaccessadditionalapplicationpages.
1 2 3 4
5 6
D12580-2
ScreenitemDescription
1Waypoint—selecticontoaccessthewaypointlist.
SelectandholdonicontoplaceaManOverboard(MOB)
markeratyourvessel’scurrentposition.
2MyData—thisiconenablesyoutocentrallymanageyour
listsofroutes,tracks,andwaypoints.
3
Customize—selectthisicontocongureapplication
pagesandselectthedisplay'slanguage,units,date/time,
boatdetailsanddisplaypreferences.
4
Set-up—selectthisicontoaccessthesystemset-up
menus.
5
Page—eachiconrepresentsanapplicationpage.A
pagecandisplayupto2applicationssimultaneously.
6
Statusbar—thestatusiconsconrmthestatusof
externally-connectedequipment,includingGPS,AIS,
radar,andautopilotunits.
6.8Homescreenoverview—Newc
Series/NeweSeries
Thehomescreenprovidesacentralpointofaccesstoyour
display'srangeofapplications.
•Thehomescreenalsoprovidesquickaccesstoyourdata
(waypoints,routes,andtracks).
•Thehomescreenconsistsofanumberofapplication"pages",
eachrepresentedbyanicon.Applicationscanbestartedby
selectingtherelevantpageicon.
•Usethejoystickorswipethescreenwithyournger(Newe
Seriesonly)toscrollthehomescreenandaccessadditional
applicationpages.
D12195-2
1 2 3 4
6 5
ScreenitemDescription
1
TouchLock—(HybridTouchdisplaysonly)selectthis
icontolockthetouchscreen,preventingaccidentaluse.
Tounlock,usetheUniControltodeselecttheTouch
Lockicon.
2MyData—thisiconenablesyoutocentrallymanage
yourlistsofroutes,tracks,andwaypoints.
3
Customize—selectthisicontocongureapplication
pagesandselectthedisplay'slanguage,units,
date/time,boatdetailsanddisplaypreferences.
4
Set-up—selectthisicontoaccessthesystemset-up
menus.
5
Page—eachiconrepresentsanapplicationpage.A
pagecandisplayupto2applicationssimultaneously.
6
Statusbar—thestatusiconsconrmthestatusof
externally-connectedequipment,includingGPS,AIS,
radar,andautopilotunits.
Accessingthehomescreen
Thehomescreencanbeaccessedfromanyapplication.
Toaccessthehomescreenfollowthestepsbelow:
1.Selectthehomescreeniconon-screen.
Accessingthehomescreen
Thehomescreencanbeaccessedfromanyapplication.
Toaccessthehomescreenfollowthestepsbelow:
1.PresstheHomebutton.
Note:Thee7ande7DhaveacombinedMenuandHome
button,toaccessthehomescreenpressandholdtheMenu/
Homebuttonfor3seconds.
76NewaSeries/NewcSeries/NeweSeries

Raymarine E70012 - c97 MFD Specifications

General

Display Size	9 inches
Display Resolution	800 x 480 pixels
Chartplotter	Yes
Sonar Support	Yes
Waterproof Rating	IPX6
Cartography	Raymarine LightHouse charts
Touchscreen	Yes
Radar Compatibility	Yes
Networking	NMEA 2000
GPS Receiver	Built-in
