4. Attach the lens cap to the lens cap holder.
A. Pull tab on side of the lens cap to remove it C. Attach it to the lens cap holder on the side of
from lens on camcorder. the camcorder.
Lens Cap
on Holder
5. Adjust the hand strap.
A. Unsnap the flap and open the adjustment strap.
B. Put your hand in the hand strap.
C. Pull the adjustment strap to tighten.
D. Snap the flap closed.
6.
Insert a cassette in the camcorder.
OPEN
Button
-_---
Cassette
Compartment
Cover
Cassette
F
Compartment
A. Slide
OPEN
and completely open the
cassette compartment cover.
B. Press
EJECT
to open the cassette
compartment.
C. Insert a cassette with the safety tab facing up
and the tape window facing out.
D. Gently press on the compartment where it is
labeled PUSH until it locks into place.
E. After the cassette compartment is fully
retracted, close the compartment cover.
12
