5.04
WHEELTRIMS
Central wheeltrim 1
Masked wheel bolts
Remove it using a wheeltrim key
(located in the glove box) by
inserting spanner 2 into recess 3.
To refit it, align recess 3 with the
rim, clip the wheeltrim into
position and use spanner 2 to
tighten the nut.
We would advise you to note the
number engraved on the key so that
you can replace it if it is lost.
Wheeltrim 4
Masked wheel bolts
Remove it using a wheeltrim key A
(stored with the tools).
To refit it, align the valve symbol
(engraved on the wheeltrim) with
the valve 5 andclipitbackin
position.
