FUSES
(continued)
Allocation
of
fuses
(depending
on
the
equipment
level)
Symbol
Allocation
Heated
rear
screen
Horn
Anti-lock
braking
(ABS)
Left-hand
side
lights/
“lights
on”
warning
buzzer/instrument
panel/number
plate
light
Right-hand
side
lights
Rear
fog
light
Right-hand
main
beam
headlight
Left-hand
main
beam
headlight
Right-hand
dipped
beam
headlight/headlight
beam
adjustment
Left-hand
dipped
beam
headlight
Stop
lights/instrument
panel/heated
windscreen/
ABS/childproof
rear
window
risers
Symbol
Allocation
Radio/cigarette
lighter/
instrument
lighting/clock
Accessories
socket
Fan
-
heater/air
conditioning
Engine
cooling
fan
Headlight
washer
Remote
control/engine
immobiliser
Injection/engine
immobiliser
Flasher
unit
Symbol
Allocation
Sunroof
Electric
windows
W
i
ndscreen
wash/wipe
Heated
seats
De-icing
door
mirrors
Electric
door
locking/
interior
lights/
luggage
compartment
lighting
Front
fog
lights
Circuit
breaker
(clock,
radio,
et
c.)
Reversing
lights/
rear
screen
wash/wipe
Air
conditioning
Dual
headlamps
174
176
