5.19
FUSES
Fuse box 1
If a fault occurs in an electrical
component, first of all check that
the fuses are sound.
Open the cover 2 (under the steering
wheel).
To identify the fuses, refer to label 4
(shown on the page opposite).
It is advisable not to use the free
fuse locations.
Check the fuse in question
and replace it, if
necessary, with a fuse
which must be of the
same rating as the original fuse.
If a fuse is fitted where the rating is
too high, it may cause the
electrical circuit to overheat (risk
of fire) in the event of an item of
equipment using an excessive
amount of current.
CORRECT INCORRECT
Use tweezers to remove fuse 3.
To remove the fuse from the tweezers,
slide the fuse to the side.
A wise precaution:
obtain a box of spare bulbs and
fuses from your RENAULT Dealer .
