Table 6-59, Table 6-60, Table 6-61, Table 6-62, Table 6-63, Table 6-64 below details the function of the
switches associated with the GPT & POEG & Timer.
Table 6-59: GPT & POEG & Timer Configuration Switch Settings (1)
SW6-1
Explanation
ON
Enable the external bus signal.
OFF
Enables signals other than the external bus. (CAN, Emulator, I
2
C, etc.)
Table 6-60: GPT & POEG & Timer Configuration Switch Settings (2)
SW5-7
SW5-6
SW5-5
Explanation
ON
OFF
OFF
Enable the "M1_VP" signal.
OFF
ON
OFF
Enable the "RS485_RXD" signal.
OFF
OFF
ON
Enable the "SCI_RXD" signal.
Table 6-61: GPT & POEG & Timer Configuration Switch Settings (3)
SW5-4
SW5-3
Explanation
ON
OFF
Enable the "M1_UN" signal.
OFF
ON
Enable the "SCI_RTS" signal.
Table 6-62: GPT & POEG & Timer Configuration Switch Settings (4)
SW6-8
SW6-7
Explanation
ON
OFF
Enable the "MB_RST#" signal.
OFF
ON
Enable the "M1_WN" signal.
Table 6-63: GPT & POEG & Timer Configuration Switch Settings (5)
SW6-6
SW6-5
Explanation
ON
OFF
Enable the "SCI_TXD" signal.
OFF
ON
Enable the "M1_VN" signal.
Table 6-64: GPT & POEG & Timer Configuration Switch Settings (6)
SW6-4
SW6-3
Explanation
ON
OFF
Enable the "M2_POE" signal.
OFF
ON
Enable the "TRACE_CTL" signal.
