Model
GPD15-5S:CirculationPump
CheckPoint
(CircuitBoard)
CN9
Function
Providescirculationthroughtheheatexchanger.
FailureEvent
Water󰘱owisnotdetected.
E󰘯ects
①Unitdoesnotoperate.
②Circulationpumpisnotoperating.
ErrorCode
Er44,Er60
Diagnostic
①Visualinspection:checkwiringforproperconnection.
②Checksupplyvoltage.
Color/WireNumber
InternalCHprimarycirculationpump:Connector(blue⑨,brown③)
1
2
3
4
5
6
7
8
9
10
11
12
