Ricoh Aficio MP C4502 User Manual

Loading Paper into the Small Size Paper Tray
• Check the paper edges are aligned at the right side.
• If a paper tray is pushed vigorously when putting it back into place, the position of the tray's side
fences may slip out of place.
• When loading a low number of sheets, be sure not to squeeze the side fences in too tightly. If the
side fences are squeezed too tightly against the paper, the edges may crease, thin paper may
wrinkle, or the paper may be misfed.
1. Carefully pull out the paper tray until it stops.
CJW027
2. Square the paper and load it print side up.
Do not stack paper over the limit mark.
CJW028
3. Carefully push the paper tray fully in.
• For details about how to install the small size paper tray, see "Installing the Small Size Paper Tray",
Getting Started .
9. Adding Paper and Toner
142
