Ricoh Aficio MP C4502 User Manual

2. Getting Started
This chapter describes how to start using this machine.
Guide to Names and Functions of Components
Guide to Components of Types 1 and 2
• Do not obstruct the ventilation holes by placing objects near them or leaning things against them. If
the machine overheats, a fault might occur.
Front and left view
4
1
2
3
5
6
7
8
9
CJS001
1. ARDF
Lower the ARDF over originals placed on the exposure glass.
If you load a stack of originals in the ARDF, the ARDF will automatically feed the originals one by one. The
ARDF scans both sides of an original one side at a time.
27
