Uninstalling
If software was installed incorrectly or incompletely, uninstall and then re-install it.
Before uninstalling software or deleting devices, turn off any other printers connected to your
computer via USB, or disconnect the USB cable to the printers.
Screens vary according to the operating environment.
To re-install the software, restart Windows.
When re-installing the software, see page 50 "Confirming the Connection Method".
Uninstalling the Printer Driver
The Status Monitor installed with the current printer driver is uninstalled when the current printer
driver is uninstalled.
1. Press and hold down the [Power] key for one second.
2. On the [Start] menu, click [Devices and Printers].
For Windows Vista or Windows Server 2008, click [Control Panel], and then click [Printers] in
[Hardware and Sound].
For Windows XP, click [Printers and Faxes].
Windows Server 2003/2003 R2, point to [Settings], and then click [Printers and Faxes].
3. Right-click the machine icon, and then click [Remove device].
For Windows XP/Vista or Windows Server 2003/2003 R2/2008, right-click the machine icon,
and then click [Delete].
4. Click [Yes].
The printer driver is uninstalled.
5. Select an arbitrary printer, and then click [Print server properties].
For Windows XP/Vista or Windows Server 2003/2003 R2/2008, click [Server Properties] on
the [File] menu.
6. Click the [Drivers] tab.
7. In the [Installed printer drivers:] list, select [Printer Name], and then click [Remove].
For Windows XP/Vista or Windows Server 2003/2003 R2/2008, go to Step 9.
8. Troubleshooting
216

Table of Contents

Other manuals for Ricoh aficio SG 2100N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh aficio SG 2100N and is the answer not in the manual?

Ricoh aficio SG 2100N Specifications

General IconGeneral
Maximum resolution3600 x 1200 DPI
Time to first page (black, normal)5.5 s
Time to first page (color, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)29 ppm
ColorYes
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle10000 pages per month
Number of print cartridges4
Page description languagesRPCS
Sustainability certificatesENERGY STAR
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantity1
Maximum print size210 x 297 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Internal memory32 MB
Total input capacity250 sheets
Total output capacity100 sheets
Wi-FiNo
Supported network protocolsTCP/IP
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)1.06 W
Power consumption (printing)22.8 W
Networking featuresFast Ethernet
Compliance industry standardsIEEE 802.3, IEEE 802.3u
Product colorBlack, White
Market positioningHome & office
Weight and Dimensions IconWeight and Dimensions
Depth360 mm
Width399 mm
Height212.5 mm
Weight9500 g
