Status Monitor Errors
If an error occurs with the machine, the Status Monitor displays an error message. Click [User Guide...]
to display the page corresponding to the error where you can check how to resolve the problem in more
detail.
Depending on the "Auto Continue" settings specified on the [System] menu, some of the following
messages might not appear. See page 145 "Using the [System] Menu".
Status Monitor Does Not Open
If the Status Monitor does not open for a shared printer, refer to the following questions:
Are the share settings correct?
• Check the share settings of the printer. The printer driver must also be installed on the client
computer.
See page 72 "Setting up a server", page 83 "Using as the Windows Network Printer".
• If Windows Firewall is installed on the print server, configure exceptions in the firewall before using
the Status Monitor.
1. On Windows Firewall dialog box, click the [Exception] tab, and then select the [File and Print
Sharing] check box.
2. Click [Add Port...], make sure [TCP] is selected, and then enter "55665" in [Port number].
No Response from Machine
Follow the procedure below to check the port settings and the connection between the machine and
computer.
1. Check that the power of the machine is on.
2. Make sure that the computer and machine are properly connected using a USB cable.
3. On the [Start] menu, click [Devices and Printers].
For Windows Vista or Windows Server 2008, click [Control Panel]. Then click [Hardware and
Sound], and then click [Printers].
For Windows XP, click [Printers and Faxes].
For Windows Server 2003/2003 R2, point to [Settings], and then click [Printers and Faxes].
4. Right-click the machine icon, and then click [Printer properties].
For Windows Vista/XP or Windows Server 2003/2003 R2/2008, right-click the machine icon,
and then click [Properties].
Status Monitor Errors
253
