Ricoh aficio SG 2100N User Manual

13. If you want to make initial settings for the printer, click [Set Now] or [OK].
14. Make initial settings, and then click [OK].
15. Click [Finish].
16. Click [Finish].
If a dialog box asking whether you want to restart now appears, select [Yes, restart now.], and
then click [Finish].
• Although the Windows security warning may appear during installation, ignore it and continue with
the installation.
• A message appears if there is a newer version of the printer driver already installed. If this is the
case, you cannot install the printer driver using Auto Run. See page 245 "If a Message Appears
during Installation".
Using as the Windows Network Printer
This section assumes that the client has already been configured to communicate with a print server. Do
not begin the following procedure before the client is set up and configured correctly.
To use the print server, install the printer driver by selecting "Network printer server", and then select the
shared printer.
• Only administrators and power users can perform this installation. Log on as a member of the
Administrators or Power Users group.
• If you print with a print server connected to the printer using the SmartDeviceMonitor port,
Recovery Printing and Parallel Printing cannot be used from the client.
• If you print with a Windows XP/Vista/7 or Windows Server 2003/2003 R2/2008 print server,
notification functions of SmartDeviceMonitor may not be used with the client.
1. Insert the CD-ROM in the CD-ROM drive.
Quit all applications currently running.
2. Select an interface language, and then click [OK].
3. Click [PCL/RPCS Raster Printer Drivers] or [Printer Driver].
4. Read the entire license agreement carefully. If you accept its terms, click [I accept the
agreement.], and then click [Next >].
5. Select the program you want to use, and then click [Next >]. (SG 3110DN/SG
3110DNw)
6. Select the model of printer you want to use. (SG 3110DN/SG 3110DNw/SG 7100DN)
Click [Connect to a printer port or LAN], and then click [Next >]. (SG 2100N)
Installing the Printer Drivers for a Network Connection
83

Ricoh aficio SG 2100N Specifications

General

Maximum resolution	3600 x 1200 DPI
Time to first page (black, normal)	5.5 s
Time to first page (color, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	10000 pages per month
Number of print cartridges	4
Page description languages	RPCS
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Maximum print size	210 x 297 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Internal memory	32 MB
Total input capacity	250 sheets
Total output capacity	100 sheets
Wi-Fi	No
Supported network protocols	TCP/IP
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.06 W
Power consumption (printing)	22.8 W
Networking features	Fast Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Product color	Black, White
Market positioning	Home & office

Weight and Dimensions

Depth	360 mm
Width	399 mm
Height	212.5 mm
Weight	9500 g
