Ricoh Aficio SP C320DN User Manual

Connecting to the standard Ethernet port
1. Remove the cable cover.
CBK233
2. Connect the Ethernet cable to the Ethernet port.
CBK088
3. Connect the other end of the cable to the network, for example using a hub.
4. Attach the cable cover.
CBK234
Connecting to the Ethernet port of the Gigabit Ethernet board
1. Attach the ferrite core to the Ethernet cable.
Attach the other ferrite core about 10 cm (4 inches) ( ) from this core making a loop as shown.
4. Connecting the Printer
70
4
