Ricoh GR Digital II User Manual

12
If you are using the camera for the first time, read this section.
Open the package and make sure all the items are included.
GR DIGITAL II
The serial number of the camera is
provided on the bottom face of the
camera.
Hot Shoe Cover
Included with the camera.
USB Cable (mini-B type)
Used to connect the camera to a
computer or direct print-
compatible printer.
AV Cable
Used to view your images on a TV.
Rechargeable Battery
Battery Charger
Handstrap
Note ---------------------------------------
Attaching the handstrap to the
camera
Thread the small end of the strap
through the strap eyelet on the
camera and loop the ends as shown.
Packing List

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
