Ricoh GR Digital II User Manual

177
Changing Camera Settings
5
When [Info Disp] is set to [On], information is displayed on the
picture display in the following cases even when the picture display
is turned off in shooting mode (GP.56). (Only information, not the
shooting screen, is displayed.) This is useful when using the
external viewfinder.
• When the t (Self-timer) button or N (Macro) button is pressed.
• When the mode dial setting is switched.
• When the up-down dial is rotated.
• When the ADJ. lever is pressed to the left or right during manual
exposure mode (GP.79).
• When [AF/MF], [AF/Snap], [JPEG>RAW], [Color>B&W], or
[Color>TE] is set in [Function Button] (GP.164) and the Fn
(Function) button is pressed.
• When the F (Flash) OPEN switch is pressed to open the flash.
After the information is displayed and operations are performed for
several seconds, or when the shutter release button is half-pressed,
the information display disappears and the picture display turns off
again.
1 Display the setup menu.
• For the operating procedure, see P.156.
2 Press the " button to select [Info Disp] and press the $
button.
3 Press the !" buttons to select
[On].
4 Press the MENU/OK button, or
press the # button and then
the MENU/OK button.
Displaying Information When the
Picture Display is Off (Info Disp)

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
