Ricoh GR Digital II User Manual

220
7
Appendices
Specifications
Image Sensor 10.01 million effective pixels (Total 10.3 million pixels), 1/1.75" CCD
Lens Focal Length 5.9 mm (equivalent to 28 mm on a 35-mm camera)
F-aperture F2.4 to F11 (Auto shooting mode Use with ND filter when F7.1 or higher)
Shooting
Distance
Approx. 30 cm to A (from the front edge of the lens)
Approx. 1.5 cm to A (Macro shooting, from the front edge of the lens)
Lens
Construction
6 elements in 5 groups (2 aspherical lens elements with 3 surfaces)
Zoom Magnification Digital zoom at 4.0 times, Auto resize zoom at approx. 5.7 times (VGA
image)
Focus Modes Multi AF (CCD method)/Spot AF (CCD method)/MF/Snap/A (with
Focus Lock, AF Aux. Light)
Shutter
Speed
Still Image 180, 120, 60, 30, 15, 8, 4, 2, 1 to 1/2000 seconds (The upper and lower
limits differ for each shooting mode and flash mode.)
Movie 1/30 to 1/2000 seconds
Exposure
Control
Exposure
Metering Mode
Multi Light Metering (256 segments)/Center-weighted Light Metering/
Spot Metering (TTL-CCD Metering, AE Lock available)
Exposure Mode Program AE, Aperture Priority AE, Manual Exposure
Exposure
Compensation
Manual exposure compensation (+2.0 to -2.0EV in 1/3EV Steps), Auto
bracket function (–0.5 EV, ±0, +0.5 EV/ –0.3 EV, ±0, +0.3 EV)
ISO Sensitivity
(Standard Output Sensitivity)
Auto/Auto-Hi/ISO 80/ISO 100/ISO 200/ISO 400/ISO 800/ISO 1600
White Balance Mode Auto/Outdoors/Cloudy/Incandescent Lamp/Fluorescent Lamp/Manual
Settings/Detail/White balance bracket function
Flash Flash Mode Auto flash (during low light and when subject is backlight)/Red-eye
Flash/Flash On/Flash Synchro/Flash Off
Built-in flash
Range
Approx. 20 cm to 3.0 m (ISO Auto)
Flash
Compensation
±2.0EV (1/3 EV Steps)
Picture Display 2.7" Transparent Amorphous Silicon TFT LCD, approx. 230,000 pixels
Shooting Mode Auto shooting mode/Program shift mode/Aperture priority mode/Manual
exposure mode/Scene mode (Text Mode/Movie/Skew Correct Mode)/
My Settings Mode
Picture Quality Mode
*1
F (Fine), N (Normal), RAW (DNG file format)
*2
Number of
Recorded
Pixels
Still Image 3648 × 2736, 3648 × 2432, 2736 × 2736,
3264 × 2448, 2592 × 1944, 2048 × 1536,
1280 × 960, 640 × 480
Movie 640 × 480, 320 × 240
Text 3648 × 2736, 2048 × 1536
Recording Media SD memory card, SDHC memory card, MultiMedia card, Internal
Memory (approx. 54 MB)

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
