Ricoh GR Digital II User Manual

32
If you are using the camera for the first time, read this section.
Loading AAA Alkaline Batteries
(Available in Stores)
Insert the batteries in the direction
shown.
Close the battery/card cover by sliding
the release lever while pressing close the
battery/card cover with your finger.
Removing the SD Memory Card
Slide the release lever toward OPEN to open the battery/card
cover. Push in the SD memory card and gently release to eject it.
Pull the card out of the camera.
Removing the Rechargeable Battery
Slide the release lever toward OPEN to open the battery/card
cover. Press and release the latch. The battery is ejected. Pull the
battery out of the camera. Be careful not to drop the battery when
removing it from the camera.
Removing the AAA Alkaline Batteries
Slide the release lever toward OPEN to open the battery/card
cover, and then remove the alkaline batteries. Be careful not to drop
the alkaline batteries when removing them from the camera.
Caution-----------------------------------------------------------------------------------------------
• When closing the battery/card cover, slide the release lever and be sure to lock it in
place.
• Remove the batteries if you are not going to use the camera for a long period of time.
Store the removed batteries in a dry cool place.

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
