If you are using the camera for the first time, read this section.
19
Rear View
Item Name Refer to
1 Picture Display P.23
2 Auto Focus/Flash Lamp P.33, 38, 41, 44
3 AV Output Terminal P.147
4 USB Terminal P.150, 205, 206, 209
5 ADJ. Lever P.64
6 8 (Englarged View) Button P.41, 51
7 9 (Thumbnail Display) Button P.41, 49
8 !/MODE button P.83
9 $/F (Flash) Button P.44
10 MENU/OK Button P.89, 133, 156
11 O (DISP.) Button P.56
12
"
/N (Macro) Button
P.43
13 #/Fn (Function) Button P.69
14 6 (Playback) Button P.47
15
D
(Delete)/t (Self-timer) Button
P.52, 46
16 Terminal Cover P.147, 150, 205, 206,
209
17 Speaker P.132
18 Power (DC input) Cable Cover P.225
19 Release Lever P.31, 225
20 Battery/Card Cover P.31, 225
21 Tripod Screw Hole P.220
1
2
4
8
9
7
6
12
11
10
13 15
514
3
1716 1918 2120
To Next Page
