2.Replacement and Adjustment
26
2. Replacement and Adjustment
Doors and Covers
Front Door and Covers
Top Covers, Rear Cover
1. Remove the top right edge cover ( x2).
2. Disconnect the top flat cover [A] and slide it in the direction of the arrow ( x2).
