2.Replacement and Adjustment
50
2. Remove the sensor bracket [A] ( x 1, x 1, x 1)
3. Remove the lift sensor [A] ( )
Exit Sensor
1. Remove the exit sensor [A] ( x1, x1, x1).
Paper Height Sensors, Paper Size Sensors
1. Remove the rear cover. (Front Door and Covers)
2. Remove the right cover. (Front Door and Covers)
3. Remove the main control board bracket. (Main Control Board Bracket)
4. Remove the paper height sensor unit [A] x2, x 1, x 4).
Remove the paper height sensors [B] ( x 4 each).
