Ricoh LCIT RT5130 User Manual

2.Replacement and Adjustment
51
Remove the paper size sensors [C] ( x 1 each).
Main Control Board
Main Board
1. Remove the rear cover (Front Door and Covers)
2. Remove the main control board [A] ( x 7, x 1, x All)
Main Control Board Bracket
1. Remove the rear cover (Front Door and Covers)
