2.Replacement and Adjustment
41
3. Remove the vertical transport motor [A] ( x2, x1)
Re-installation
Make sure that the tension spring is connected, then tighten the screw .
5th Transport Motor
Remove:
 Rear cover (Front Door and Covers)
[A] Motor unit ( x4, x 1).
[B] Spring (x1). First, loosen screw ( x 1).
