Guide to Components
This section introduces the names of the various parts on the front and rear side of the machine and
outlines their functions.
Exterior
• Type 1 and 3 model is not equipped with an Auto Document Feeder (ADF).
• Type 1, 3, 4 and 6 models do not come with an Ethernet port.
• Type 1, 2 and 3 models do not come with a line port or TEL port.
1. Exposure Glass
Place originals here sheet by sheet.
2. Control Panel
Contains a screen and keys for machine control. For details, see page 21 "Control Panel".
3. Front Cover
Open this cover to replace consumables or clear a paper jam.
