Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-121
:MEASure:SETup:PSB
Syntax
:MEASure:SETup:PSB <source>
:MEASure:SETup:PSB?
Description
Set or query source B of Phase 1→2 and Phase 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MEASure:SETup:PSB CHANnel2 /*Set source B of phase measurement to CH2*/
:MEASure:SETup:PSB? /*The query returns CHAN2*/
Related
Command
:MEASure:ITEM
:MEASure:SETup:DSA
Syntax
:MEASure:SETup:DSA <source>
:MEASure:SETup:DSA?
Description
Set or query source A of Delay 1→2 and Delay 1→2 measurements.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MEASure:SETup:DSA CHANnel1 /*Set source A of delay measurement to CH1*/
:MEASure:SETup:DSA? /*The query returns CHAN1*/
Related
Command
:MEASure:ITEM
