Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-13
:CHANnel<n>:TCAL
Syntax
:CHANnel<n>:TCAL <val>
:CHANnel<n>:TCAL?
Description
Set or query the delay calibration time of the specified channel to calibrate the zero offset
of the corresponding channel. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
--
<val>
Real
-100ns to 100ns
0.00s
Explanation
<val> can only be set to the specific values in the specified step. If the parameter you
sent is not one of the specific values, the parameter will be set to the nearest specific
values automatically. The step varies with the horizontal timebase (set by
the :TIMebase[:MAIN]:SCALe command), as shown in the table below.
Horizontal Timebase
Step of the Delay Calibration Time
5ns
100ps
10ns
200ps
20ns
400ps
50ns
1ns
100ns
2ns
200ns
4ns
500ns
10ns
1μs to 10μs
20ns
Note: When the horizontal timebase is equal to or greater than 10μs, the delay
calibration time cannot be adjusted.
Return
Format
The query returns the delay calibration time in scientific notation.
Example
:CHANnel1:TCAL 0.00000002 /*Set the delay calibration time to 20ns*/
:CHANnel1:TCAL? /*The query returns 2.000000e-08*/

Rigol DS1104Z-S Plus Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GSa/s
Channels	4
Memory Depth	24 Mpts
Vertical Resolution	8 bits
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	2 ns/div to 1000 s/div
Waveform Record	Up to 60, 000 frames
FFT	Yes
Waveform Capture Rate	30, 000 wfms/s
Display	7-inch TFT LCD
Trigger Modes	Edge, Pulse, Video, Window, Timeout
Interfaces	USB, LAN
Serial Bus Triggering and Decoding	I2C, SPI, UART
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
