Rigol DS1104Z-S Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-17
:CURSor:MANual
Command List:
 :CURSor:MANual:TYPE
 :CURSor:MANual:SOURce
 :CURSor:MANual:TUNit
 :CURSor:MANual:VUNit
 :CURSor:MANual:AX
 :CURSor:MANual:BX
 :CURSor:MANual:AY
 :CURSor:MANual:BY
 :CURSor:MANual:AXValue?
 :CURSor:MANual:AYValue?
 :CURSor:MANual:BXValue?
 :CURSor:MANual:BYValue?
 :CURSor:MANual:XDELta?
 :CURSor:MANual:IXDELta?
 :CURSor:MANual:YDELta?
:CURSor:MANual:TYPE
Syntax
:CURSor:MANual:TYPE <type>
:CURSor:MANual:TYPE?
Description
Set or query the cursor type in manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<type>
Discrete
{X|Y}
X
Explanation
 X: select the X type cursors. The X type cursors are a vertical solid line (cursor A) and
a vertical dotted line (cursor B) and are usually used to measure the time
parameters.
 Y: select the Y type cursors. The Y type cursors are a horizontal solid line (cursor A)
and a horizontal dotted line (cursor B) and are usually used to measure the voltage
parameters.
 When the channel source of manual cursor measurement is set to LA
(:CURSor:MANual:SOURce), the cursor type cannot be set to Y.
Return
Format
The query returns X or Y.
Example
:CURSor:MANual:TYPE Y /*select the Y type cursors*/
:CURSor:MANual:TYPE? /*The query returns Y*/
