:TRIGger:DELay:TLOWer
Syntax
:TRIGger:DELay:TLOWer <NR3>
:TRIGger:DELay:TLOWer?
Description
Set or query the lower limit of the delay time in delay trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
Related to the delay type
GREater: 8ns to 10s
GOUT or GLESs: 8ns to 9.99s
1μs
Explanation
This command is only available when the delay type (refer to :TRIGger:DELay:TYPe) is
GREater, GOUT, or GLESs.
Return
Format
The query returns the lower limit of the delay time in scientific notation.
Example
:TRIGger:DELay:TLOWer 0.002 /*Set the lower limit of the delay time to 2ms*/
:TRIGger:DELay:TLOWer? /*The query returns 2.000000e-03*/
Related
Command
:TRIGger:DELay:TUPPer

Rigol DS1104Z-S Plus Specifications

General

Bandwidth	100 MHz
Sample Rate	1 GSa/s
Channels	4
Memory Depth	24 Mpts
Vertical Resolution	8 bits
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	2 ns/div to 1000 s/div
Waveform Record	Up to 60, 000 frames
FFT	Yes
Waveform Capture Rate	30, 000 wfms/s
Display	7-inch TFT LCD
Trigger Modes	Edge, Pulse, Video, Window, Timeout
Interfaces	USB, LAN
Serial Bus Triggering and Decoding	I2C, SPI, UART
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
