Rigol DS1104Z-S Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-47
:DECoder<n>:UART:STOP
Syntax
:DECoder<n>:UART:STOP <stop>
:DECoder<n>:UART:STOP?
Description
Set or query the stop bit after each frame of data in RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<stop>
Discrete
{1|1.5|2}
1
Return
Format
The query returns 1, 1.5, or 2.
Example
:DECoder1:UART:STOP 1.5 /*Set the stop bit in RS232 decoding to 1.5*/
:DECoder1:UART:STOP? /*The query returns 1.5*/
:DECoder<n>:UART:PARity
Syntax
:DECoder<n>:UART:PARity <parity>
:DECoder<n>:UART:PARity?
Description
Set or query the even-odd check mode of the data transmission in RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<parity>
Discrete
{NONE|EVEN|ODD}
NONE
Return
Format
The query returns NONE, EVEN, or ODD.
Example
:DECoder1:UART:PARity ODD /*Set the even-odd check mode in RS232 decoding to
odd*/
:DECoder1:UART:PARity? /*The query returns ODD*/
