Rockwell Automation B Series User Manual

Rockwell Automation Publication 520-UM001I-EN-E - July 2016 161
Troubleshooting Chapter 4
F081 DSI Comm Loss 2 Communications between the drive and
the Modbus or DSI master device have
been interrupted.
• Cycle power.
• Check communications cabling.
• Check Modbus or DSI setting.
• Check Modbus or DSI status.
• Modify using C125
[Comm Loss
Action].
• Connecting I/O terminals C1 and C2
to ground may improve noise
immunity.
• Replace wiring, Modbus master
device, or control module.
F082 Opt Comm Loss 2 Communications between the drive and
the network option card have been
interrupted.
• Cycle power.
• Reinstall option card in drive.
• Modify using C125
[Comm Loss
Action].
• Replace wiring, port expander,
option card, or control module.
F083
(1)
EN Comm Loss 2 Internal communications between the
drive and the embedded EtherNet/IP
adapter have been interrupted.
• Cycle power.
• Check EtherNet/IP setting.
• Check drive’s Ethernet settings and
diagnostic parameters.
• Modify using C125 [Comm Loss
Action].
• Replace wiring, Ethernet switch, or
control module.
F091
(1)
Encoder Loss 2 Requires differential encoder.
One of the 2 encoder channel signals is
missing.
• Check Wiring.
• If P047, P049, P051 [Speed
Referencex] = 16 “Positioning” and
A535 [Motor Fdbk Type] = 5 “Quad
Check”, swap the Encoder channel
inputs or swap any two motor leads.
• Replace encoder.
F094 Function Loss 2 “Freeze-Fire” (Function Loss) input is
inactive, input to the programmed
terminal is open.
Close input to the terminal and cycle
power.
F100 Parameter Chksum 2 Drive parameter non-volatile storage is
corrupted.
Set P053
[Reset To Defalts] to 2 “Factory
Rset”.
F101 External Storage 2 External non-volatile storage has failed. Set P053 [Reset To Defalts] to 2 “Factory
Rset”.
F105 C Connect Err 2 Control module was disconnected while
drive was powered.
Clear fault and verify all parameter
settings. Do not remove or install the
control module while power is applied.
F106 Incompat C-P 2 The PowerFlex 525 control module does
not support power modules with 0.25
HP power rating.
• Change to a different power module.
• Change to a PowerFlex 523 control
module.
F107 Replaced C-P 2 The control module could not recognize
the power module. Hardware failure.
• Change to a different power module.
• Replace control module if changing
power module does not work.
F109 Mismatch C-P 2 The control module was mounted to a
different drive type power module.
Set P053
[Reset To Defalts] to 3 “Power
Reset”.
F110 Keypad Membrane 2 Keypad membrane failure /
disconnected.
• Cycle power.
• Replace control module if fault
cannot be cleared.
F111
(1)
Safety Hardware 2 Safety input enable hardware
malfunction. One of the safety inputs is
not enabled.
• Check safety input signals. If not
using safety, verify and tighten
jumper for I/O terminals S1, S2 and
S+.
• Replace control module if fault
cannot be cleared.
Fault Types, Descriptions and Actions
No. Fault Type
(2)
Description Action
