236 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Appendix G Safe-Torque-Off Function
EC Type Examination
Certification
TÜV Rheinland has certified the PowerFlex 525 Safe-Torque-Off function
compliant with the requirements for machines defined in Annex I of the
EC Directive 2006/42/EC, and that it complies with the requirements of the
relevant standards listed below:
• EN ISO 13849-1 Safety of machinery – Safety related parts of control
systems – Part 1: General principles for design.
(PowerFlex 525 STO achieves Category 3 / PL(d))
• EN 61800-5-2 Adjustable speed electrical power drive systems – Part 5-2
Safety requirements – Functional.
(PowerFlex 525 STO achieves SIL CL 2)
• EN 62061 Safety of machinery – Functional safety of safety-related
electrical, electronic and programmable electronic control systems.
• IEC 61508 Part 1-7 Functional safety of electrical/electronic/
programmable electronic safety-related systems – Parts 1-7.
TÜV also certifies that the PowerFlex 525 STO may be used in applications up to
Category 3/ PL(d) according to EN ISO 13849-1 and SIL 2 according to
EN 62061 / EN 61800-5-2 / IEC 61508.
The TÜV Rheinland certificate may be found at:
www.rockwellautomation.com/products/certification/
.
EMC Instructions
PowerFlex 525 Safe-Torque-Off function requires CE Conformity as described
on page 52
.
Using PowerFlex 525 Safe-
Torque-Off
The PowerFlex 525 Safe-Torque-Off function is intended to be part of the safety
related control system of a machine. Before use, a risk assessment should be
performed that compares the PowerFlex 525 Safe-Torque-Off function
specifications and all foreseeable operational and environmental characteristics of
the machine to which it is to be fitted.
ATTENTION: Electric Shock Hazard. Verify that all sources of AC and DC power
are de-energized and locked out or tagged out in accordance with the
requirements of ANSI/NFPA 70E, Part II.
To avoid an electric shock hazard, verify that the voltage on the bus capacitors has
discharged before performing any work on the drive. Measure the DC bus voltage
at the +DC and -DC terminals or test points (refer to your drive’s User Manual for
locations). The voltage must be zero.
In safe-off mode, hazardous voltages may still be present at the motor. To avoid an
electric shock hazard, disconnect power to the motor and verify that the voltage is
zero before performing any work on the motor.
