24 Rockwell Automation Publication 520-UM001I-EN-E - July 2016
Chapter 1 Installation/Wiring
Fuses and Circuit Breakers for PowerFlex 520-Series Drives 100...120V 1-Phase Input Protection Devices – Frames A...B 200...240V 1-Phase Input Protection Devices – Frames A...B
(1) When the drive is controlling motors with lower amp ratings, refer to the drive nameplate for drive input current rating. (2) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection Circuit Breakers Application Ratings
.
(3) Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(4) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 480Y/277 and 600Y/347 AC input. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance ground systems. (5) Circuit breaker selection is not available for this drive rating.
Catalog No. Output Ratings Input
Ratings
Frame Size
Contactor
Catalog No.
IEC Applications (Non-UL) UL Applications
PF 523 PF 525 ND HD
Amps
kVA
Max Amps
(1)
Fuses (Rating) Circuit Breakers Fuses (Max. Rating) Circuit Breakers Min.
Enclosure Vol. (in.
3
)
HP kW HP kW Min. Max. 140U/140G 140M Class / Catalog No. 140U/140G 140M
(2)(3)(4)
25A-V1P6N104 – 0.25 0.2 0.25 0.2 1.6 0.8 6.4 A 100-C09 10 16 140U-D6D2-B80 140M-C2E-B63 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-B80 140M-C2E-B63 – 25A-V2P5N104 25B-V2P5N104 0.5 0.4 0.5 0.4 2.5 1.3 9.6 A 100-C12 16 20 140U-D6D2-C12 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-20 140U-D6C2-C12 140M-C2E-C10 – 25A-V4P8N104 25B-V4P8N104 1.0 0.75 1.0 0.75 4.8 2.5 19.2 B 100-C23 25 40 140U-D6D2-C25 140M-D8E-C20 CLASS RK5, CC, J, or T / DLS-R-40 140U-D6D2-C25 140M-D8E-C20 – 25A-V6P0N104 25B-V6P0N104 1.5 1.1 1.5 1.1 6.0 3.2 24.0 B 100-C23 32 50 140U-D6D2-C30 140M-F8E-C25 CLASS RK5, CC, J, or T / DLS-R-50 140U-D6D2-C30 140M-F8E-C25 – Catalog No. Output Ratings Input
Ratings
Frame Size
Contactor
Catalog No.
IEC Applications (Non-UL) UL Applications
PF 523 PF 525 ND HD
Amps
kVA
Max Amps
(1)
Fuses (Rating) Circuit Breakers Fuses (Max. Rating) Circuit Breakers Min.
Enclosure Vol. (in.
3
)
HP kW HP kW Min. Max. 140U/140G 140M Class / Catalog No. 140U/140G 140M
(2)(3)(4)
25A-A1P6N104 – 0.25 0.2 0.25 0.2 1.6 1.4 5.3 A 100-C09 6 10 140U-D6D2-C10 140M-C2E-B63 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-B63 – 25A-A1P6N114 – 0.25 0.2 0.25 0.2 1.6 1.4 5.3 A 100-C09 6 10 140U-D6D2-C10 140M-C2E-B63 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-B63 – 25A-A2P5N104 25B-A2P5N104 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 16 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10 – 25A-A2P5N114 25B-A2P5N114 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 16 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10 – 25A-A4P8N104 25B-A4P8N104 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 16 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16 – 25A-A4P8N114 25B-A4P8N114 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 16 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16 – 25A-A8P0N104 25B-A8P0N104 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS CC, J, or T / 40 140U-D6D2-C25 140M-F8E-C25 – 25A-A8P0N114 25B-A8P0N114 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS CC, J, or T / 40 140U-D6D2-C25 140M-F8E-C25 – 25A-A011N104 25B-A011N104 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 32 50 140G-G6C3-C35 140M-F8E-C25 CLASS CC, J, or T / 50 –
(5)
140M-F8E-C25 –
25A-A011N114 25B-A011N114 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 32 50 140G-G6C3-C35 140M-F8E-C25 CLASS CC, J, or T / 50 –
(5)
140M-F8E-C25 –
