Rockwell Automation Publication 520-UM001I-EN-E - July 2016 41
Installation/Wiring Chapter 1
13 For Series A
0-10V In
(1)
Not Active For external 0-10V (unipolar) input supply or potentiometer
wiper.
Input impedance:
Voltage source = 100 kΩ
Allowable potentiometer resistance range = 1...10 kΩ
P047, P049,
t062, t063,
t065, t066,
t093, A459,
A471
For Series B
Analog Input
Not Active External analog input supply, selectable by Analog Input
jumper. Default is 0-10V (unipolar) input supply or
potentiometer wiper.
Input impedance:
Voltage source = 100 kΩ
Allowable potentiometer resistance range = 1...10 kΩ
Change Analog Input jumper to 4-20 mA for external 4-20 mA
input supply. Input impedance = 250 Ω
P047, P049,
t062, t063,
t065, t066,
t093, A459,
A471
14 Analog Common – Return for the analog I/O. Electrically isolated (along with the
analog I/O) from the rest of the drive.
–
15 For Series A
4-20mA In
(1)
Not Active For external 4-20 mA input supply.
Input impedance = 250 Ω
P047, P049,
t062, t063,
t065, t066,
A459, A471
For Series B
Analog Output
OutFreq 0-10 The default analog output is 0-10V. To convert a current value,
change the Analog Output jumper to 0-20 mA. Program with
t088 [Analog Out Sel]. Maximum analog value can be scaled
with t089 [Analog Out High].
Maximum Load: 4-20 mA = 525 Ω (10.5V)
0-10V = 1 kΩ (10 mA)
t088, t089
C1 C1 – This terminal is tied to the RJ-45 port shield. Tie this terminal to
a clean ground in order to improve noise immunity when using
external communication peripherals.
–
C2 C2 – This is the signal common for the communication signals. –
(1) Only one analog frequency source may be connected at a time. If more than one reference is connected at the same time, an
undetermined frequency reference will result.
(2) See Footnote (1) on page 39
.
Control I/O Terminal Designations
No. Signal Default Description Parameter
