10
Apr. 2014 CUBE-STEX
Plane View (View 5, 6)
fig.view-56.eps
View 5
View 6
e
c
b
e e
e
ee
b
c
View 6
View 5
No. Part Code Part Name Description Q’ty
b 5100013786 SCREW 4X12 (JC7000193R0) TRUSS TAPTITE P BZC 7
c 5100005101 WASHER RESIN 4.1X11X1 BLACK 7
No. Part Code Part Name Description Q’ty
e 5100020467 SCREW 4X15 (501-11044-06-00) BINDING TAPTITE P BZC 20
