Plane View (View 7, 8)
fig.view-78.eps
View 7
View 8
f
b e
e
e
View 7
View 8
No. Part Code Part Name Description Q’ty
f 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 4
No. Part Code Part Name Description Q’ty
b 5100013786 SCREW 4X12 (JC7000193R0) TRUSS TAPTITE P BZC 6
e 5100020467 SCREW 4X15 (501-11044-06-00) BINDING TAPTITE P BZC 4
