Plane View (View A1, A2)
fig.view-A12.eps
View A1
View A2
g
g
f
View A2
View A1
No. Part Code Part Name Description Q’ty
f 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 4
No. Part Code Part Name Description Q’ty
g 5100034002 SCREW M3X12 PAN MACHINE W/SMW+PW BZC 5
