7
Apr. 2014 CUBE-STEX
Exploded View Parts List
Disassembly Procedure
1. Remove screws b (7) and washers c (7) in View 5 (p. 10), and detach the
grill assy (24).
2. Remove the screws e (8) attaching the woofer (23) in View 6 (p. 10).
3. Disconnect the speaker wires from the terminal of the woofer and detach
the woofer.
4. Remove screws b (4) in View 1 (p. 8).
5. Remove screws b (6) in View 8 (p. 11).
6. Detach the connector for the power supply cable (black and white)
connecting to the battery jack inside of the rear case.
7. Detach the rubber sponge bushing (11), then also detach the speaker
wires disconnected from the woofer from the interior of the rear case, and
then remove the chassis.
No. Part Code Part Name Description Q’ty
1 5100004814 HANDLE HOLDER 08343-512 4
2 5100004813 HANDLE PLATE 08492-511 (SD000462) 1
3 5100004812 HANDLE RUBBER 08492-511 (SD000461) 1
4 5100038982 HANDLE 1
5 5100011382 HANDLE PLATE 750-11038-03-00 1
6 5100039398 HIMELON HANDLE 4
7 5100038980 HANDLE HOLDER PLATE 4
8 5100039394 HIMELON L 2
9 5100039395 HIMELON M 2
10 5100039396 HIMELON S 4
11 5100017151 RUBBER SPONGE BUSHING 1
12 5100009062 BATTERY TERMINAL 2
13 5100010782 CUSHION BATTERY TERMINAL 2
14 5100022626 BATTERY PACK (990-11046-10-00 AA X 8 PCS 1
15 5100038354 REAR CASE 1
16 5100038981 TOP HAT HOLDER PLATE 1
17 5100039397 HIMELON TOPHAT 3
18 5100009845 STAND ADAPTOR (TOP HAT) 49A-10179 (#17055020) 1
19 5100027159 RUBBER FOOT D30.5XT9.5 8
20 5100038353 FRONT CASE 1
21 5100039421 CUSHION GRILLE 2
22 5100039225 SPEAKER T0204-045A 2
23 5100039224 SPEAKER W0804-045A 2
24 5100038544 GRILLE ASSY 1
To Next Page
