16
Apr. 2014 CUBE-STEX
Plane View (View A5, A6)
fig.view-A56.eps
View A5
View A6
f
A27
View A5
View A6
No. Part Code Part Name Description Q’ty
A27 5100010540 EVA PACKING (429-AP011-DH) FOR DC JACK HOLDER A 1
No. Part Code Part Name Description Q’ty
f 40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 2
