21
Apr. 2014 CUBE-STEX
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100038353 FRONT CASE 1
# 5100038544 GRILLE ASSY 1
5100004812 HANDLE RUBBER 08492-511 (SD000461) 1
# 5100038982 HANDLE 1
# 5100038356 PANEL SHEET 1
# 5100038354 REAR CASE 1
5100009845 STAND ADAPTOR (TOP HAT) 49A-10179 (#17055020) 1
CHASSIS
# 5100038355 CHASSIS 1
5100004813 HANDLE PLATE 08492-511 (SD000462) 1
5100011382 HANDLE PLATE 750-11038-03-00 1
5100004814 HANDLE HOLDER 08343-512 4
# 5100038980 HANDLE HOLDER PLATE 4
# 5100038981 TOP HAT HOLDER PLATE 1
KNOB, BUTTON
# 5100038983 R-KNOB SF BLK/SLV 8
5100023950 R-KNOB 10-11017-01-01 6
5100032968 C-KEYTOP SD1H CLR 1
5100036682 S-KEYTOP 1
SWITCH
02897801 SEESAW SWITCH SDDJE13200 94V-0 1
5100000485 SLIDE SWITCH SV71040F-0102-9T-NP 1
04459978 SLIDE SWITCH SV70050F-0202-10T-NN 1
5100007725 SWITCH SS71020F-0103-6T-025-NP-017 1
01780101 TACT SWITCH SKQKABD010 2
JACK, EXT TERMINAL
# 5100037105 3.5MM JACK LJE0393-7 1
13449146 6.5MM JACK YKB21-5012 (W/SW) 2
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 6
5100014678 CANNON CONNECTOR CT/PJ-02-EP 2
03562412 DC JACK HEC3900-010110 1
SPEAKER, BUZZER
# 5100039224 SPEAKER W0804-045A 2
# 5100039225 SPEAKER T0204-045A 2
PWB ASSY
# 5100038562 MAIN SHEET ASSY 1
* This unit includes the following parts.
******** MAIN BOARD 1
******** AUDIO INPUT BOARD 1
******** INPUT BOARD 1
# 5100038548 PANEL SHEET ASSY 1
* This unit includes the following parts.
******** JACK BOARD 1
******** LINE INPUT BOARD 1
******** PANEL L BOARD 1
******** PANEL R BOARD 1
DIODE
5100019878 LED (RED) L-710XSURD-E-SZ 8
5100019879 LED (GREEN) L-710XVGD-E-SZ 1
To Next Page
