13
Apr. 2014 CUBE-STEX
Exploded View (Fig. A) Parts List
No. Part Code Part Name Description Q’ty
A1 5100023950 R-KNOB 10-11017-01-01 6
A2 5100032952 JACK NUT 2
A3 5100038983 R-KNOB SF BLK/SLV 8
A4 40128923 HEX NUT M7 H5039521R0 1 attached to VR
A5 17048630 VR ACCESSORY NUT M9 13 attached to VR
A6 17048651 VR ACCESSORY WASHER M7 M7X12X0.5 NO.476 1 attached to VR
A7 40452178 VR WASHER M9 13 attached to VR
A8 5100038356 PANEL SHEET 1
A9 02897801 SEESAW SWITCH SDDJE13200 94V-0 1
A10 5100039400 CUSHION B 2
A11 5100039399 CUSHION A 1
A12 5100032952 JACK NUT 6
A13 5100027106 CORD HOOK 40516-014 1
A14 5100038355 CHASSIS 1
A15 5100039401 CUSHION C 1
5100038562 MAIN SHEET ASSY 1
* This unit includes the following parts.
A16 ******** INPUT BOARD 1
A17 ******** AUDIO INPUT BOARD 1
A24 ******** MAIN BOARD 1
5100038548 PANEL SHEET ASSY 1
* This unit includes the following parts.
A18 ******** LINE INPUT BOARD 1
A20 ******** PANEL R BOARD 1
A22 ******** PANEL L BOARD 1
A23 ******** JACK BOARD 1
A19 5100032968 C-KEYTOP SD1H CLR 1
A21 5100036682 S-KEYTOP 1
To Next Page
