48
Chapter 3 - Preparations
3-4. Cutter Installation Method 3 (Diamond Scraper)
2. Menu Settings
5
Fully loosen the lock nut.
6
Use the menus to set [AUTO Z CONTROL] to ON.
(1) Press several times to display the screen shown at right.
(2) Press
to move the blinking cursor to [OTHERS], then press .
(3) Press
several times to display the screen shown at right.
(4) Press to move the blinking cursor to [ON], then press .
7
Use the menus to set [REVOLUTION] to OFF.
(1) Press several times to display the screen shown at right.
(2) Press
to move the blinking cursor to [OTHERS], then press .
(3) Press to move the blinking cursor to [OFF], then press .
8
Press several times to return to the top screen.
Be sure to loosen the lock nut.
X 0 Y 0
Z 0 8000RPM
I/O OTHERS
TEACHING SELF
REVOLUTION
ON <OFF>
AUTO Z CONTROL
<ON> OFF
I/O OTHERS
TEACHING SELF
To Next Page
