49
Chapter 3 - Preparations
3-4. Cutter Installation Method 3 (Diamond Scraper)
3. Cutter Installation
9
Lower the spindle until the tip of the collet is at
a height about 5 to 10 mm (1/4 to 1/2 in.) from
the surface of the table.
10
Insert the diamond scraper, then bring the tip
lightly into contact with the table.
11
Use the included hexagonal screwdriver to
tighten the tool securing screw.
12
Close the spindle cover.
5 to 10 mm (1/4 to 1/2 in.)
1.
2.
3.
To Next Page
