Roland RD-800 User Manual

* “[A]+[B]” indicates the operation of “holding down the [A] button and pressing the [B] button.”
Shortcut Explanation Page
Basic operation
[SHIFT] + [DEC] [INC], value dial
Makes the value change more greatly.
When switching tones, the rst sound in the category is selected. When switching Live Sets, the rst sound in the bank
is selected.
p. 13, p. 17
[SHIFT] + [
] [ ] If the Layer Edit screen or MIDI Control screen is shown, move between pages. p. 28, p. 37
Registering the desired sounds in a TONE or LIVE SET
Currently selected TONE button + [WRITE]
Memorizes the currently selected Tone number.
The next time you press the same button, the memorized Tone will be selected.
p. 13
Currently selected LIVE SET button + [WRITE]
Memorizes the currently selected Live Set number.
The next time you press the same button, the memorized Live Set will be selected.
p. 13
Changing the order of Live Sets (Live Set Swap)
[SHIFT] + LIVE SET [A] – [J] Changes the order of Live Sets. p. 23
Editing a tone or Live Set
[TRANSPOSE] + keyboard, [DEC] [INC], value dial Species the transposition setting of the entire keyboard. p. 12
[SPLIT/LOWER SELECT] +
TONE button, [DEC] [INC] , value dial
Selects the LOWER tone when using Split. p. 13
[SPLIT/LOWER SELECT] + keyboard Species the split point. p. 13
[RHYTHM/SONG] + [DEC] [INC]
When rhythm is selected, species the rhythm volume.
When an audio song is selected, species the audio volume.
p. 24, p. 25
[SHIFT] + LAYER switch ( [UPPER1] – [LOWER] ) Jumps to the Designer Menu screen for each layer. p. 32
[SHIFT] + LAYER LEVEL slider (*1) Jumps to the VOL (Volume) item of the Layer Edit screen. p. 28, p. 38
[SHIFT] + [TRANSPOSE] (*1) Jumps to the C.Tune (Coarse Tune) item of the Layer Edit screen. p. 28, p. 39
[SHIFT] + [SPLIT] (*1) Jumps to the KR.LWR (Keyboard Range Lower) item of the Layer Edit screen. p. 28, p. 39
[SHIFT] + [LIVE SET EDIT] Jumps to the Layer Edit screen. p. 28
Reverb
[SHIFT] + REVERB knob Jumps to the Reverb screen. p. 14, p. 31
LAYER switch ( [UPPER1] – [LOWER] ) +
REVERB knob (*1)
Adjusts each layer’s reverb depth (Reverb Send Level). p. 28, p. 38
Tone color
[SHIFT] + TONE COLOR knob Jumps to the TON CLR (Tone Color Control Destination) item of the Layer Edit screen. p. 20
EQ/DELAY/ASSIGN
[SHIFT] + each EQ knobs (LOW, MID1, MID2, HIGH) Changes the center frequency of each equalizer band. p. 15
[SHIFT] + each DELAY knobs (TYPE, LEVEL, FEEDBACK, TIME) Jumps to the Delay screen. p. 15, p. 31
[SHIFT] + DELAY [ON/OFF] Jumps to the DLY (Delay Send Level) item of the Layer Edit screen. p. 28
LAYER switch ( [UPPER1] – [LOWER] ) +
DELAY [LEVEL] knob
Adjusts each layer’s delay depth (Delay Send Level). p. 28
[SHIFT] + each ASSIGN knobs (1–4) Jumps to the Assign 1-5 screen. p. 15 p. 30
[SHIFT] + ASSIGN [5] (*1) Jumps to the A5 (Assign 5 Control Switch) item of the Layer Edit screen. p. 28, p. 39
Modulation FX
MOD FX [ON/OFF] + [DEC] [INC], value dial Changes the modulation FX type of the layer that’s selected in Modulation FX Control Destination. p. 14
[SHIFT] + MOD FX [DEPTH], [RATE] knob Jumps to the Modulation FX screen of the layer that’s selected in Modulation FX Control Destination. p. 35
[SHIFT] + MOD FX [ON/OFF] Jumps to the MOD FX (Modulation FX Control Destination) item of the Layer Edit screen. p. 28
Tremolo/amp simulator
TREMOLO [ON/OFF] + [DEC] [INC], value dial
Changes the tremolo/amp simulator type of the layer that’s selected in Tremolo/Amp Control Destination. p. 14
AMP SIM [ON/OFF] + [DEC] [INC], value dial
[SHIFT] + TREMOLO [DEPTH], [RATE] knob
Jumps to the Tremolo/Amp Simulator screen of the layer that’s selected in Tremolo/Amp Control Destination. p. 35
[SHIFT] + AMP SIM [DRIVE] knob
[SHIFT] + TREMOLO [ON/OFF]
Jumps to the TR/AMP (Tremolo/Amp Control Destination) item of the Layer Edit screen. p. 28
[SHIFT] + AMP SIM [ON/OFF]
S1/S2
[SHIFT] + [S1] Jumps to the S1/S2 screen. p. 30
[SHIFT] + [S2] (*1) Jumps to the S2 item of the Layer Edit screen. p. 28, p. 39
Pitch bend lever/modulation lever
[SHIFT] + pitch bend lever (*1) Jumps to the PB (Pitch Bend Control Switch) item of the Layer Edit screen. p. 28, p. 39
[SHIFT] + modulation lever (*1) Jumps to the MD (Modulation Control Switch) item of the Layer Edit screen. p. 28, p. 39
Pedal
[SHIFT] + pedal (DAMPER) (*1) Jumps to the DAMP (Damper Control Switch) item of the Layer Edit screen. p. 28, p. 39
[SHIFT] + pedal (FC1, FC2, EXT) Jumps to the Pedal screen. p. 29
Panel lock
[MENU] + [ENTER] Enables panel lock. p. 12
When entering a name
[SHIFT] + [ ] Switch character sets. p. 23, p. 25
[SHIFT] + [
] Switch uppercase/lowercase. p. 23, p. 25
[SHIFT] + [
] Delete one character (DELETE). p. 23, p. 25
[SHIFT] + [
] Insert one space (INSERT). p. 23, p. 25
*1: If the [MIDI CONTROL] button is lit, makes settings for the External layer.
List of Shortcut Keys
