Roland SoundCanvas SC-88 Pro User Manual

< Modifying values >
Since the Speed parameter has only two values, Slow
and Fast, the lower half of the range (00H -- 3FH) will
select Slow, and the upper half (40H--7FH) will select
Fast.
B0 10 00 Speed → Slow
::
B0 10 3F Speed → Slow
B0 10 40 Speed → Fast
::
B0 10 7F Speed → Fast
● Using Control Change 16 to modify the
Wah Man value of 50:GTR Multi3
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2. Set the effect type to 50: GTR Multi 3 (value: 04H
02H)
F0 41 10 42 12
40 03 00 04 02 37 F7
3. Set Wah Man (address: 40H 03H 04H) to 0.
F0 41 10 42 12
40 03 04 00 39 F7
4. Set Effect Control Source 1 (address: 40H 03H 1BH)
to CC16 (10H).
F0 41 10 42 12
40 03 1B 10 12 F7
5. Set Effect Control Depth 1 (address: 40H 03H 1CH)
to +100% (7FH).
F0 41 10 42 12
40 03 1C 7F 22 F7
< Modifying the value >
B0 10 00 Wah Man → 0
B0 10 01 Wah Man → 1
::
B0 10 7E Wah Man → 126
B0 10 7F Wah Man → 127
* For the correspondence between the hexadecimal val-
ues and the parameter values, refer to p.183.
● Using Control Change 17 to modify the
Feedback value of 10: Stereo Flanger
Example 1: When Effect Control Depth is set to
+100
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12
40 41 22 01 5C F7
2. Set the effect type to 10: Stereo Flanger (value: 01H
23H)
F0 41 10 42 12 40 03 00 01 23 19 F7
3. Set Feedback (address: 40H 03H 08H) to -98%.
F0 41 10 42 12
40 03 08 00 35 F7
4. Set Effect Control Source 2 (address: 40H 03H 1DH)
to CC17 (11H).
F0 41 10 42 12
40 03 1D 11 0F F7
5. Set Effect Control Depth 2 (address: 40H 03H 1EH)
to +100% (7FH).
F0 41 10 42 12
40 03 1E 7F 20 F7
< Modifying the value >
The Feedback parameter changes in 2% steps, with 40H
as the center. (For the correspondence between hexa-
decimal values and parameter values, refer to the table
on p.183.)
B0 11 00 Feedback → -98%
::
B0 11 0F Feedback → -98%
B0 11 10 Feedback → -96%
::
B0 11 3E Feedback → -4%
B0 11 3F Feedback → -2%
B0 11 40 Feedback → +/-0%
B0 11 41 Feedback → +2%
B0 11 42 Feedback → +4%
::
B0 11 70 Feedback → +96%
B0 11 71 Feedback → +98%
::
B0 11 7F Feedback → +98%
● Using Control Change 17 to modify the
Feedback value of 10: Stereo Flanger
Example 2: When Effect Control Depth is set to -
100
< Settings >
1. Turn EFX on for Part 1.
F0 41 10 42 12 40 41 22 01 5C F7
2. Set the effect type to 10: Stereo Flanger (value: 01H
23H)
F0 41 10 42 12
40 03 00 01 23 19 F7
3.
Set Feedback (address: 40H 03H 08H) to +98% (7FH).
F0 41 10 42 12 40 03 08 7F 36 F7
4. Set Effect Control Source 2 (address: 40H 03H 1DH)
to CC17 (11H).
F0 41 10 42 12
40 03 1D 11 0F F7
5. Set Effect Control Depth 2 (address: 40H 03H 1EH)
to -100% (00H).
F0 41 10 42 12
40 03 1E 00 1F F7
< Modifying the value >
The Feedback parameter changes in 2% steps, with 40H
as the center. (For the correspondence between hexa-
decimal values and parameter values, refer to the table
on p.183.) Since Effect Control Depth is set to -100%,
increasing control change values will cause the value of
the Feedback parameter to decrease.
B0 11 00 Feedback → +98%
::
B0 11 0F Feedback → +98%
B0 11 10 Feedback → +96%
::
B0 11 3E Feedback → +4%
B0 11 3F Feedback → +2%
B0 11 40 Feedback → +/-0%
B0 11 41 Feedback → -2%
B0 11 42 Feedback → -4%
::
B0 11 70 Feedback → -96%
B0 11 71 Feedback → -98%
::
B0 11 7F Feedback → -98%
Chapter 4. Insertion Effects
94

Roland SoundCanvas SC-88 Pro Specifications

Sound Specifications

maximum polyphony	64 voices
preset sounds	1117
drum sound set	42

User Sound Settings

user sounds	256
user drum sound set	2
user effect	64

Effects

reverb types	8
chorus types	8
delay types	10

Display

display size	70.6 x 24.5 mm
display type	backlit LCD

Power

power supply	AC117V, AC230V or 240V
power consumption	16W (AC117V), 16W (230V/240V)

Weight and Dimensions

dimensions (mm)	218 (W) x 250 (D) x 72 (H)
dimensions (inches)	8-5/8 (W) x 9-7/8 (D) x 2-7/8 (H)
weight	2.6 kg
