Roland SoundCanvas SC-88 Pro User Manual

● Procedure for creating and storing a sound
1. Make sure that the [ALL] indicator is dark.
If it is lit, press the [ALL] button to turn it off.
2. Use PART [ll
ll
] [rr
rr
] to select a normal Part, then use the INSTRUMENT [ll
ll
]
[rr
rr
] buttons to select the sound you wish to start from.
Your edits will apply to this sound.
3. Press [USER INST] and [SELECT] simultaneously, the indicator light red.
Be aware that if this indicator is not lit, you will be editing not User Instrument parame-
ters but Part parameters (p.31).
4. Press the [SELECT] button and select the parameter you wish to modify.
Use the appropriate parameter edit buttons [ll
ll
] [rr
rr
] to modify the value.
For an explanation of parameters and the procedure for modifying them, refer to p.31.
(Example) Vibrato editing display
PART
INSTRUMENT
A16
100 0
LEVEL
PAN
032 Gt.Harmonics
INSTRUMENTPA R T
LEVEL
PA N
REVERB
CHORUS
KEY SHIFT
MIDI CH
DELAY
ALL
MUTE
SC
-
55
MAP
SC
-
88
MAP
1
2
2
SELECT
EFX ON/OFF
USER
INST
VIB RATE
AT TACK
VIB DEPTH
CUTOFF
DECAY
VIB DELAY
RESONANCE
RELEASE
EFX VALUEEFX PARAMEFX TYPE
PART
INSTRUMENT
A01
100
0
LEVEL
PAN
Vib. |+20|± 0|± 0|
Rate
Depth
Delay
Select the sound parameter
4
3
Chapter 5. Convenient functions
97

Roland SoundCanvas SC-88 Pro Specifications

Sound Specifications

maximum polyphony	64 voices
preset sounds	1117
drum sound set	42

User Sound Settings

user sounds	256
user drum sound set	2
user effect	64

Effects

reverb types	8
chorus types	8
delay types	10

Display

display size	70.6 x 24.5 mm
display type	backlit LCD

Power

power supply	AC117V, AC230V or 240V
power consumption	16W (AC117V), 16W (230V/240V)

Weight and Dimensions

dimensions (mm)	218 (W) x 250 (D) x 72 (H)
dimensions (inches)	8-5/8 (W) x 9-7/8 (D) x 2-7/8 (H)
weight	2.6 kg
