Data management via the FR-1x’s USB port
42
r
FR-1x V-Accordion
Loading new sounds from a USB
memory (optional)
The FR-1x allows you to add new sounds to the internal
sounds. The new sounds (files with the “.Bl3” extension)
must be copied to a USB memory’s root directory, after
which you can load them with the FR-1x. “Loading”
means that they will be copied to a permanent internal
memory area. There are two such memory areas (“1”
and “2”).
1.
Insert an optional USB memory into the
FR-1x’s USB MEMORY port.
2.
Press and hold down the [SET] register.
The display shows the name of the last parameter
you selected.
3.
Use treble register [3] or [4] (PARAM LIST)
to select “Snd” (Sound).
4.
Use treble registers [1] and [2] (VALUE) to
select the number of the sound file you
want to load from the connected USB mem-
ory.
If the USB memory doesn’t contain any sound files,
the display will show “---” instead of a number.
5.
Press the [USER PROGRAM] (ENTER) button
to confirm your selection.
The FR-1x suggests memory area “1” as target for the
selected file.
6.
Use treble registers [1] and [2] (VALUE) to
select the desired target memory area (1 or
2).
7.
Press the [USER PROGRAM] (ENTER) button
to load the selected sound set.
The display shows “Lod” (Load) to indicate that the
data are being loaded (this may take 1.5 minutes).
Next, the “don” (Done) message appears to signal
that the file was loaded successfully.
NOTE
The new sounds can only be used if you also load the asso-
ciated User Sets and select one of those.
PIANO/GUITAR
WIND
Snd
FR-1x GB.book Page 42 Tuesday, November 8, 2011 11:44 AM
