Section 03 787 RFI ENGINE
Subsection 04 (BOTTOM END)
Useapresstoremovethegearno. 14 from the
counterbalance shaft.
F00D0TA
CLEANING
General
Discard all oil seals, gaskets, O-rings and sealing
rings.
Clean oil passages and make sure they are not
clogged.
Clean all metal components in a solvent.
Crankshaft
Clean crankshaft end with sand paper no.180 and
remove all residue using pulley flange cleaner
(P/N 413 711 809).
A32CB5A
TYPICAL
Crankcase
Crankcase mating surfaces are best cleaned us-
ing a combination of the chisel gasket remover
(P/N 413 708 500) and a brass brush. Brush a first
pass in one direction then make the final brushing
perpendicularly (90°) to the first pass cross (hatch).
CAUTION: Never use a sharp object to scrape
away old sealant as score marks incurred are
detrimental to crankcase sealing.
F00D2BA
smr2005-083 93
