Royal Enfield Bullet 350 User Manual

32
DRIVE CHAIN TENSION (Free Play 25-30mm)
 Loosen axle nut, spindle nut, anchor
nut and brake rod nut.
 Turn the adjuster cams on both sides,
till 25 to 30 mm slackness is achieved.
MINOR MAINTENANCE TIPS
 Check and ensure that the number of notches from
the punch mark on the cam to the notch resting on
the pin are equal on both sides.
 Apply brake and tighten all nuts.
REAR BRAKE
 Turn in or out the adjuster nut at
the brake rod end.
 The recommended brake pedal
travel is 20 to 30 mm.
 Check that the brake is not
binding and the rear wheel
rotates freely.
REAR BRAKE PEDAL HEIGHT
 Loosen the lock nut
 Turn in or out the pedal stop pin
till the brake pedal and front foot
rest are in the same height as
shown in fig.
 Tighten the lock nut
 Check for free rotation of rear
wheel.
20 to 30mm

Royal Enfield Bullet 350 Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Displacement	346 cc
Max Power	19.1 bhp @ 5250 rpm
Max Torque	28 Nm @ 4000 rpm
Transmission	5 Speed Constant Mesh
Fuel Capacity	13.5 Liters
Brakes Rear	153 mm Drum
Tyre Size Front	3.25 x 19
Tyre Size Rear	3.25 x 19
Seat Height	800 mm
Ground Clearance	135 mm
Wheelbase	1370 mm
Brakes Front	280 mm disc
Fuel System	Fuel Injection
