EB 2517 EN 13
Markings on the device
2.3 Material number
2.3.1 Type 2417 Valve
See the nameplate (11, body material). For
more details on the nameplate, see sec-
tion2.1.
2.3.2 Type2413 Actuator
SpecifyingthecongurationID,youcancon-
tactustondoutwhichmaterialisused.The
congurationIDisspeciedonthename-
plate(3,congurationID).Formoredetails
onthenameplate,seesection2.1.
Nameplate
position
Fig.2: Nameplate on the body ange of the Type2417 and on the Type2413 Actuator (diaphragm
or metal bellows)
2.2 Nameplate position
Î RefertoFig.2.
